KND 5 -25 x 56 Sniper Scope

KND 5 -25 x 56 Sniper Scope

FFP Reticle Optics for Long-Range Observation and Precision Aiming

The KND312 / KND525 Sniper Rifle Scopes are designed for long-range observation and precision aiming. Continuous variable magnification and high light transmission deliver clear imagery, supporting target tracking and identification across varying distances.

The first focal plane (FFP) reticle maintains consistent angular subtensions throughout the magnification range, supporting range estimation and aiming corrections. Adjustable reticle illumination enhances aiming-point visibility against complex backgrounds and in low-light conditions. With smooth mechanical controls, the KND series provides controlled operation for reconnaissance and precision shooting applications.

Environmental conditions

Waterproof
1m derinlik - 30 dakika
Storage temperature
-40 °C / +70 °C
Standard
MIL-STD-810H
Operating temperature
-30 °C / +55 °C
Standard Accessories

Picatinny Adapter

Protection Case

Transportation Bag

Lens & Eyepiece Protection Covers

Optical Cleaning Kit

Optional Accessories

Mounted Holder for Various Weapons

Special Mounted Holder Design on Request

ADDITIONS

Product name Product Description
ARN 12 Reflex Sight

The ARN12 Reflex Sight is designed for rapid target acquisition and precision aiming with a parallax-free optical design. Night vision compatibility and multiple reticle brightness settings support clear aiming-point visibility in daylight and low-light conditions.

A MIL-STD-1913 Picatinny mount enables standardized integration with different weapon platforms. Built to meet MIL-STD-810G environmental requirements, its rugged housing supports reliable operation from −32 °C to +55 °C. With water resistance at a depth of one meter for 30 minutes, the ARN12 provides a durable reflex sight solution for demanding field conditions.

A600 Night Vision Attachment

The A600 Clip-On Night Vision Device mounts in front of an existing day sight, adding night vision capability without re-zeroing. Its 1× optical design preserves the day sight’s original zero, while image intensification technology delivers clear imagery in low-light conditions.

Recommended for use with day scopes at magnifications up to 12×, this night vision clip-on system supports a rapid transition from daytime to nighttime operation. Powered by a single AA battery and designed for integration across different platforms, the A600 extends the nighttime observation and aiming capabilities of existing optical systems.

T350-D / T360-D Thermal Weapon Sight

The TIMSAH T350-D / T360-D series combines thermal weapon sight and thermal clip-on functionality in one system. Featuring a 640 × 480 uncooled detector operating in the 8–12 µm LWIR band, it provides thermal imaging for nighttime observation and surveillance. Automatic image optimization, an OLED display and selectable polarity modes support image interpretation across changing conditions.

The series offers 1× magnification in clip-on mode and 2× magnification in weapon sight mode, with additional 2× and 4× electronic zoom available in weapon sight mode. A ballistic reticle, image and video recording with 32 GB internal storage, and an optional wireless head-up display provide operational flexibility.

Technicial Specifications

Magnification
1X
Window Size
25mm x 19mm ±10%
Dot Size
2 MOA
Azimuth/Elevation Adjustment
0.1 mrad
Azimuth/Elevation Movement
1 MOA /click
Weight
50 g ±10%
Battery
1x CR2032

Technicial Specifications

Magnification
1X
Field of View
12.5°
Min. Focus Distance
10.9 m
Weight
695 G
Battery
1x AA 1.5 Vdc
Mechanical Interface or Optic Interface
MIL-STD-1913(Picatinny)
Maintains Day Optic Zero
Yes
Compatible with 1x -4x and 1.5x - 6x Day Optics
Yes
Compatible with 3-12x Magnified Optics
Yes

Technicial Specifications

Operating Wavelength
8-12 µ (LWIR)
Detector Type
Uncooled
Detector Resolution
640 x 480
Magnification
Attachment: 1X - Weapon Sight: 2X
Digital Zoom
2X, 4X
Display
OLED
Video Format
PAL
Color Reticle
Yes
Image Recording
Yes
Internal Memory
Yes (32GB)
Battery
Li-Ion (Rechargeable)
Operating Time
8 Hours
Field of View
12.5° x 9.4°
Weight (excluding battery and accessories)
760 g
.

Technicial Specifications

Magnification
5x-25x
Lens Diameter
56mm
Field of View
5.3m/1.5m
Parallax Correction
From 25m to infinity
Eye Distance
85mm
Azimuth / Elevation Adjustment
1cm @ 100m
Reticle Total Movement
Azimuth :±60 click Elevation: 240 click
Double Turn Indicator
Yes
Reticle
Mil-Dot
Grid Focal Plane
1. Focal Plane
Reticle Illumination
11 Levels
Diopter
-3/+2
Battery
CR2032
Weight (with mounted holder)
1100 gr
Length
430mm
